特点与用途/Features & Applications

不锈钢材料

三梁结构，精度高、抗偏载能力强

容易安装， IP67

适用于电子秤、计数秤、电子天平、皮带秤及工业称重系统

l*秤台尺寸(Max.platform size)：

100-200kg: 400mm×400mm

250-500kg: 600mm×800mm

750-2000kg: 1200mm×1200mm

Made of 17-4PH stainless steel, potted by adhesive, oil-proof, waterproof, anti-corrosive gas and medium making it suitable for all kinds of environments.

Single point parallel beam, High accuracy, high side load tolerance

Easy to install, IP67 protection

      Mainly used for electronic scales, electronic balance, price computing scales, belt scales and industrial weighing systems

安装尺寸/Mounting Dimension

配线图/Wiring Code
