特点与用途/Features & Applications
铝合金材料
精度高、抗偏载能力强
容易安装， IP67
适用于电子秤、计数秤、电子天平及工业称重系统
Made of aluminum alloy.
High accuracy, Strong ability of anti-side force
Easy to install, IP67 protection
Mainly used for electronic scales, electronic balance, price computing scales and industrial weighing systems
安装尺寸/Mounting Dimension
|
参数 |
Specifications |
技术指标/Technique |
|
额定容量 |
Capacity |
8,15,30,50,100,200kg |
|
精度等级 |
Accuracy class |
C3 |
|
输出灵敏度 |
Rated output |
2.0±10%mV/V |
|
零点输出 |
Zero balance |
±2%F.S. |
|
非线性 |
Non-linearity |
0.0166%F.S. |
|
滞后 |
Hysteresis |
0.0166%F.S. |
|
重复性 |
Repeatability |
0.02%F.S. |
|
蠕变（30min） |
Creep(30min) |
0.017%F.S. |
|
温度灵敏度漂移 |
Temp.effect on output |
0.017%F.S./10℃ |
|
零点温度漂移 |
Temp.effect on zero |
0.02%F.S./10℃ |
|
输入电阻 |
Input impedance |
420±20Ω |
|
输出电阻 |
Output impedance |
350±10Ω |
|
绝缘电阻 |
Insulation |
≥5000MΩ/100VDC |
|
激励电压 |
Recommended excitation |
5~15V |
|
*激励电压 |
Maximum excitation |
20V |
|
温度补偿范围 |
Compensated temp range |
-10~40℃ |
|
工作温度范围 |
Operation temp range |
-10~50℃ |
|
*超载 |
Safe overload |
150%F.S. |
|
极限超载 |
Ultimate overload |
300%F.S. |
|
电缆线尺寸 |
Cable size |
Φ4.6×1500mm |
|
单件重量 |
Weight approx. |
0.6kg |
|
材料 |
Material |
aluminum alloy |
|
防护等级 |
IP Class |
IP67 |
|
*秤盘尺寸 |
Max.platform size |
600mm×500mm |
受力方式/Load Direction
配线图/Wiring Code
