博兰森B105微型压力传感器
B105微型压力传感器,采用高精度电阻应变式原理
满足20N — 500N范围内的力的测量。
不锈钢材料,密封焊接,防油、防水、耐腐蚀
磨合结构设计,压式承载,安装使用方便灵活。也是一些生产设备厂家的*
*防爆型产品,可用于恶劣环境及危险性场合。
体积小巧,外型美观,
根据客户的不同应用需求,专业提供各种不同的信号输出。是一款值得信赖的高精度微型压力传感器。
安装尺寸/Mounting Dimension
Capacity(N) |
A |
20,50,100,200 |
1.6 |
300,500 |
2.3 |
特点与用途/Features & Applications
高度低,变形量小,外形尺寸小
不锈钢材料、防护等级:IP67,可定制
可定制高温性能,用于注塑、挤压等制造工艺
汽车压装、自动化组装、3C产品测试、新能源产品组装、医疗检测、机器人领域,模具组装及其他工业测试、测量及控制系统
动态响应频率高
Low profile,small deflection and mini dimension
Made of stainless steel IP66 protection,Customizable
High temperature is customizable for injection molding, extrusion and other manufacturing process
Suitable for Automotive press fit, automated assembly, 3C products testing, new energy product assembly, medical testing, robotics, mold assembly and other industrial testing and control system
High dynamic response frequency
受力方式/Load Direction
配线图/Wiring Code
