Specifications |
Technique |
|
Capacity |
0.1,0.2,0.3,0.5,1,2,3,5,10,20 30,50,100,200,300,500N.m |
|
Rated output |
1.0~1.5mV/V |
|
Zero balance |
±1% F.S. |
|
Non-linearity |
0.2%F.S. |
|
Hysteresis |
0.2%F.S. |
|
Repeatability |
0.1%F.S. |
|
Creep(30min) |
0.1%F.S. |
|
Temp.effect on output |
0.02%F.S./10℃ |
|
Temp.effect on zero |
0.02%F.S./10℃ |
|
Input impedance |
350/700±10Ω |
|
Output impedance |
350/700±10Ω |
|
Insulation |
≥2000MΩ/100VDC |
|
Recommended excitation |
12V |
|
Maximum excitation |
15V |
|
Compensated temp range |
-10~60℃ |
|
Operation temp range |
-20~60℃ |
|
Safe overload |
120%F.S. |
|
Ultimate overload |
150%F.S. |
|
Cable size |
3m |
|
IP Class |
IP66 |
Features & Applications
l Constituted by Strain gauge sensitive components and integrated circuits;
l High precision with stable and reliable performance;
l This sensor can be operated long-term in high-speed without wear ring and other wear parts, the output is OK for positive and negative torque signal;
l Both ends are keyed;
l Maximum speed of torque cannot over 4000 r / min
